Brief description:
The impact of overheating on asphalt pavement is costly for cities, as it can cause traffic markings to be "blackened" by the rubber tires of vehicles. Some cities are even forced to replace thermoplastic road signs on major roads every six months. Our high-pressure water blasting equipment can solve this problem
Description:
Function 1: Road Marking Paint Cleaning
Our water blasting spray technology is very effective in keeping the paint lines clean. Only portable water with adjustable water pressure can clean the dust and debris deposited on the surface of paint lines, making them look fresh like new marks.
Function 2: Road Marking Paint Removing
Due to the traditional methods leaving traces on the asphalt surface of roads, removing existing aging markings has always been a challenging task. Our equipment can also effectively remove existing paint lines and prepare the surface for new road markings
Water supply protection system.
Parameter:
Engine | CUMMINS |
Power | 132kw Rotation rate: 1800r/min |
Pump speed | 530 times per minute |
Ressure | 200Mpa |
Flow | 35L/min |
Bearing | Japanese NSK plunger: cemented carbide 19.1 |
High pressure seal | imported molding seal |
Forced lubrication system and oil | cooling system inlet safety rupture disc |
High pressure meter | imported |
Full-computer monitoring instrument box | Full-computer monitoring instrument box |
Booster pump | the booster pump can boost up to 6 kg |
Water supply pipeline system | stainless steel and pressure hose |
Filter | double stainless steel vertical filter, secondary filtration |
Water supply protection system | including water supply low pressure protection system |
Recovery system | SSA vacuum pump, pressure -0.4bar |
Water tank | clean water (6T) and sewage tank (customizable) |
Oil tank | 250 liters |
Working speed | 5-8m/min |
Size | 5.2m*2.2m*2.3m or 6m*2.2m*2.3m Customized |
Weight | 8T |
