Water Blasting Road Marking Removal and Cleaning Machine

  • Parameter
  • Related products
  • Inquiry
Parameter

Brief description:

The impact of overheating on asphalt pavement is costly for cities, as it can cause traffic markings to be "blackened" by the rubber tires of vehicles. Some cities are even forced to replace thermoplastic road signs on major roads every six months. Our high-pressure water blasting equipment can solve this problem



Description:

Function 1: Road Marking Paint Cleaning

Our water blasting spray technology is very effective in keeping the paint lines clean. Only portable water with adjustable water pressure can clean the dust and debris deposited on the surface of paint lines, making them look fresh like new marks.

Function 2: Road Marking Paint Removing

Due to the traditional methods leaving traces on the asphalt surface of roads, removing existing aging markings has always been a challenging task. Our equipment can also effectively remove existing paint lines and prepare the surface for new road markings

Water supply protection system.



Parameter:

Engine CUMMINS
Power 132kw  Rotation rate: 1800r/min
Pump speed 530 times per minute
Ressure 200Mpa
Flow 35L/min
Bearing Japanese NSK plunger: cemented carbide 19.1
High pressure seal imported molding seal
Forced lubrication system and oil cooling system inlet safety rupture disc
High pressure meter imported
Full-computer monitoring instrument box Full-computer monitoring instrument box
Booster pump the booster pump can boost up to 6 kg
Water supply pipeline system stainless steel and pressure hose
Filter double stainless steel vertical filter, secondary filtration
Water supply protection system including water supply low pressure protection system
Recovery system SSA vacuum pump, pressure -0.4bar
Water tank clean water (6T) and sewage tank (customizable)
Oil tank 250 liters
Working speed 5-8m/min
Size 5.2m*2.2m*2.3m or 6m*2.2m*2.3m Customized
Weight 8T
